See it All You Will Love What You See
The ThermNight Multispectral series of scopes is the culmination of technology to create the perfect aiming solution. It can be used in all weather & lighting conditions. The thermal and night vision combination allows for faster detection of targets and provides high-quality digital image for identification.
Night Vision And Thermal At The Touch of a Button
Switching between thermal and digital channels is as easy as the press of a button, conveniently positioned on the side of the scope. You can also enable Picture-in-Picture so you can see both channels at the same time, saving you time to focus on your target.
-TNC635R SPECIFICATIONS-
Physical Specifications
Net Weight
Dimensions
Storage
724g/25.6oz
232x82x78mm/9.2×3.2×3.0 inches
Bulit-in memory,64GB
LRF Maximum Measuring Range
WIFI/APP
Shock Resistance
5~1100M/5~1200yds
Yes(DNT)
800Gs
Ingress Protection
Operating Temperature
IP67
-20~50°C/-4°F~122°F
Display Specifications
Type
Display Resolution
Frame Rate
Micro-OLED
1920×1080 pixels
60Hz
Battery Power Supply
Battery Type
Operating Time
External Power Supply
21700 Battery(flat top)
5.5h
5V – Type C USB
THERMAL CHANNEL – Sensor Specifications
Resolution
Field of View(FOV)
Frame Rate
640×512 pixels
12.52° x 10.02°
50FPS
Base Magnification
Digital Zoom
Focal Length of Objective Lens
1.5x
1.5x, 2.25x,3x,3.75x,4.5x,5.25x, 6x
35mm
Pixel Size
NETD
Image Sensor
12x12um
≤18mk@25℃
Uncooled lnfrared lmage Sensor
VISIBLE LIGHT CHANNEL – Sensor Specifications
Resolution
Sensor Frame Rate
Video Record Resolution
1920*1080 pixels
60Hz
1800×1080 pixels
VISIBLE LIGHT CHANNEL – Optical Specifications
Detection Range
Field of View(FOV)
Eye-Relief
400m
5.31° x 2.99°
65mm
Base Magnification
Digital Zoom
Diopter Adjustment
5X
5X,7.5X,10X,12X,15X,17.5X,20X
±3D
IR Rating
IR Wavelength
Class 3R Eye Safe
850/940nm
