Featuring state-of-the-art thermal sensors for detecting targets and advanced high-definition digital night vision for identifying them, the TNC225R excels in delivering superior operational effectiveness in various environments and conditions.
Thermal imaging offers superior nighttime detection ranges, enhanced by digital night vision to precisely identify targets with accuracy and reliability
ThermNight TNC225R comes with a highly sensitive 12um pixel detector and an advanced algorithm enhanced 256×192 resolution combined with NETD ≤ 25mK. This allows you to detect heat signatures at further distances and positive lD your target with digital NV before engaging.
Night Vision & ThermaI Design Ensures a Safe and Memorable Hunting Experience
The Picture-In-Picture (PIP) feature integrates thermal detection and night vision identification into a single image. enabling confident engagement of intended targets with the Multi-Spectral ThermNight TNC225R.
Day Or Night, See It ALL
Equipped with the state-of-the-art SONY STARVIS 2 sensor, celebrated for its exceptional sensitivity in low-light conditions and remarkable image clarity, the ThermNight TNC225R delivers unmatched capabilities for detection and identification.
-TNC225R SPECIFICATIONS-
Physical Specifications
Net Weight
Dimensions
Storage
22.8oz
6.7*3.3*3.1 Inches
Internal Storage, 32GB
LRF Maximum Measuring Range
WIFI/APP
Bluetooth
5-1100yards
Yes
Yes
Ingress Protection
Operating Temperature
Shock Resistance
IP67
-4~122F
800Gs
Display Specifications
Type
Display Resolution
Frame Rate
Micro-OLED
1024*768 pixels
50FPS
Battery Power Supply
Battery Type
Operating Time
External Power Supply
18650 Battery(flat top)
5h
5V – Type C USB
THERMAL CHANNEL – Sensor Specifications
Resolution
Field of View(FOV)
Frame Rate
256x192px
7.03°x 5.28°
50FPS
Pixel Size
NETD
Focal Length of Objective Lens
12x12um
≤25mk@25℃
25mm
Base Magnification
Digital Zoom
Image Sensor
3X
3X,6X,9X,12X
Uncooled Infrared Image Sensor
VISIBLE LIGHT CHANNEL – Sensor Specifications
Resolution
Sensor Frame Rate
Video Record Resolution
1920*1080 pixels
60FPS
1024*768 pixels
VISIBLE LIGHT CHANNEL – Optical Specifications
Objective Lens Focal Length
Field of View(FOV)
Eye-Relief
52mm
6.13°x 3.45°
45mm/1.8 Inches
Base Magnification
Digital Zoom
Diopter Adjustment
5X
5X,7.5X,10X,12X,15X,17.5X,20X
±5D
IR Wavelength
Infrared Power
850/940nm
Class 3R Eye Safe
